2.25Cr-1Mo Steel for pressure vessels

2.25Cr-1Mo low alloy steel with V addition has high high temperature strength, excellent oxidation resistance and hydrogen brittleness, excellent processing performance and high cost performance, and has been widely used in high temperature operations in nuclear power, electric power and petrochemical fields.
The main classification society regulations are:
China /CCS, USA /ABS, Germany /GL, France /BV, Norway /DNV, Japan /NK, UK /LR, Korea /KR, Italy /RINA
info@cntiscometal.com
Product Specification
Ingredients/Data

The basic requirements of steel for boiler and pressure vessel mainly include the following three aspects:

(1) with good mechanical properties. First of all, the materials used to manufacture boilers and pressure vessels should have appropriate strength (mainly referring to yield strength and tensile strength) to prevent plastic deformation or even fracture when subjected to pressure. For boilers and medium and high temperature pressure vessels, the creep resistance of the material should also be considered, and the high temperature performance index of the material, that is, the creep limit and lasting strength, should be determined.

(2) The materials used for manufacturing boilers and pressure vessels must have good plasticity to prevent damage caused by accidental overload during the use of boilers and pressure vessels.

(3) The materials used for manufacturing boilers and pressure vessels should have high toughness, so that the boilers and pressure vessels can withstand the impact loads that may be encountered during operation. In particular, for pressure vessels with low operating temperature or ambient temperature, the impact toughness value of the material should be considered, and the impact test at the operating temperature should be carried out on the material to prevent the brittleness of the container during operation.


Name

Steel for pressure vessels

Type

Shipbuilding steel plate

Material

360A、360B;410A、410B;460A、460B;490A、490B;1Cr0.5Mo、2.25Cr1Mo

Width

1000mm,1250mm,1500mm,2000mm,3000mm,Or customized Size

Length

1m-12m, or Customized Size

Thickness

2.0mm,4.0mm,5.0mm,6.0mm,8.0mm,10.0mm,12.0mm,14.0mm,16.0mm,20.0mm,Or customized Size

Delivery Conditions

Rolling, Annealing, Quenching, Tempered or Standard

Standard

AiSi, ASTM, bs, DIN, GB, JIS

Certificate

CE, tisi, KS, JIS, GS, ISO9001

Delivery Time

within 7 days

Surface Process

Ordinary, Wire Drawing, Laminated Film



2.25Cr-1Mo is chromium molybdenum steel, low alloy high strength steel belongs to heat resistant alloy steel

2.25Cr-1Mo delivery status: Normalizing or normalizing + tempering.

2.25Cr-1Mo implementation standards: external implementation ASTM, A20/A20M standards, internal implementation ASTM, A387/A387M standards.

Chemical composition(%):

2.25Cr-1Mo

C

Si

Mn

P

S

Cr

Mo

Ni

Cu

Alt

0.07-0.15

0.15-0.50

0.40-0.80

≤0.03

≤0.03

2-2.5

0.9-1.1

≤0.3

≤0.3

≤0.02

-


Elongation A(%)≥10

Section expansion ratio (%) ≥45

Impact work Akv (J) ≥55
