Carbon structural steel is the most used in steel, the largest number, often rolled into steel, profiles and profiles, generally do not need to be directly used by heat treatment, mainly for general structure and engineering. Q195, Q215, Q235, Q255, Q275, etc., respectively, represent the grade of steel, steel grade by the letter (Q) representing the yield point, yield point value, quality, quality and other symbols in order.
Since the hardening tendency of 16Mn steel is slightly larger than that of mild steel, preheating measures are needed to prevent cold cracks when welding at low temperatures (such as open air operations in winter) or on large rigid and thick structures.
Preheating temperature of 16Mn steel under different plate thickness and different ambient temperature:
Thickness: less than 16mm,
No preheating below -10℃, preheating below -10℃ 100~150℃;
Thickness: 16~24mm:
Not lower than -5℃ is not preheating, below -5℃ preheating 100~150℃;
Thickness: 25~40mm
Not lower than 0℃ no preheating, 0℃ below preheating 100~150℃;
Thickness: 40mm or more
Preheat 100~150℃.
16Mn steel manual arc welding should be selected E50 type electrode, such as alkaline electrode E5015, E5016, for not important structures, can also choose acid electrode E5003, E5001. For welding parts with small thickness and narrow groove, E4315 and E4316 welding rods can be selected.
When 16Mn steel submerged arc welding H08MnA wire with flux HJ431(open I groove butt butt) or H10Mn2 wire with flux HJ431(open groove butt butt butt), when welding thick plate deep groove weld, H08MnMoA wire with flux HJ431 should be selected.
16Mn steel is the most widely used low alloy steel in China, and 16Mn steel used for manufacturing welding structures are 16MnR and 16Mng steel.
Chemical composition (%):
C:0.13~0.19 ，Si :0.20~0.60 ，Mn :1.20~1.60 ，Cr≤0.30 ，P≤0.030， S≤0.030， Ni≤0.30 ，Cu≤0.25
16Mn steel pipe calculation formula :[(outer diameter - wall thickness)* wall thickness]*0.02466=kg/ m (weight per meter)
Main features: good comprehensive performance, good low temperature performance, cold stamping performance, welding performance and machinable performance.
Application examples: mining, transportation, chemical and other machinery.
The density of 16Mn is 7.85, and the density of 16Mn steel plate is 7.85
Buy our products, we will provide free service
Tianjin TISCO is a professional steel supplier. With the support of the most professional steel manufacturers and a large number of customers, we can not only provide you with ordinary steel, but also help you customize special steel, special size, special process shape and other services.
Tianjin TISCO uses standard export transport packaging and bundles steel bands according to the size of the stainless steel plate. We have frequent cooperation with freight forwarders to ensure the safe arrival of goods to the port.
According to our shipping experience, a 20-foot container can hold 22 tons of stainless steel, and a 40-foot container can hold 25 tons of stainless steel. For larger orders, we ship by bulk carrier, which is cheaper. Packaging can also be customized according to customer needs.
We provide our customers with planning services, just-in-time production planning and provide customized services to meet the specific requirements of end users. Our company has been committed to improving customer service and product quality for more than ten years, providing high-value solutions for customers' businesses as the basic standard of our work.
